Standard
API SPEC 5D:2001, API Bul 5C2:1999
Size Range
OD 33–127 mm · WT 5–10 mm · Length 6–12 m
Category
Seamless Steel Pipe
Drill pipe for geological drilling and horizontal directional drilling (HDD) pipeline laying projects, transmitting power and transporting drilling mud. General geological drill pipe covers ZT-series grades (ZT380–ZT740) for environments including H2S and CO2. HDD trenchless drill rod covers G105, S135, and V150 per API SPEC 5D and SY/T 6898.2-2013.
Applications
- → Geological drilling — connecting rig to broach for power transmission and mud circulation
- → Horizontal directional drilling (HDD) — trenchless pipeline laying projects
- → Utility crossings — under roads, rivers, and built-up areas without excavation
- → Corrosive environments — H₂S and CO₂ service capability (ZT-series)
Standards & Certifications
- API SPEC 5D:2001
- API Bul 5C2:1999
- SY/T 6417-2009
- SY/T 6898.2-2013
Inspection & Testing
- → Tensile test — Yield, UTS, elongation per grade (ZT-series or G105/S135/V150); one per heat
- → Impact test (Charpy V-notch) — Required for HDD grades G105/S135/V150 — 54 J (G105/S135) or 80 J (V150) at 0 °C
- → Hardness survey — Brinell HBW on pipe body and upset/tool-joint zone per lot
- → Dimensional inspection — OD, WT, tool-joint dimensions, and straightness; 100% per lot
- → NDE — Ultrasonic + magnetic particle inspection on pipe body and tool-joint area
- → MTC — EN 10204 3.1 mill test certificate; ZT-series proprietary mill certification
Supply Enquiry — Geological HDD Drill Rod
Tell us your standard, grade, OD, wall thickness, delivery condition, quantity, and delivery port. We will respond within one business day with availability and lead time.
Request a Quote
